I6 EVO Series
Industrial SSD- Industrial M.2 PCIe SSD
Features
- M.2 2280 PCIe SSD
- Big Capacity,High Performance
- High Reliability, High Endurance
- Low Power, Low Cost
- For cost sensitive applications
Specifications of I6 EVO INDUSTRIAL M2 SSD
| Physical | |||||||
| Form Factor | M.2 2280 | ||||||
| Interface | NVMe PCIe Gen3.0x4 | ||||||
| Size | 22*42*3.7mm | ||||||
| Capcity | 128GB~1TB | ||||||
| Flash Type | TLC | ||||||
| Performance | |||||||
| Sequential Read/Write | 3100/2400MB/S | ||||||
| Random IOPS Read/Write(4K) | 70K/70K MB/S | ||||||
| Access Time | <0.1ms | ||||||
| Electrical | |||||||
| Power Supply | 3.3V±5% | ||||||
| Power Consumption | 9W(active) 0.8W(idle) | ||||||
| Temperature | |||||||
| Operating Temperature | Wide Temp.:-40℃～85℃ Industrial temp.: -20℃～+70℃ Commercial Temp.:0℃～+70℃ | ||||||
| Storage Temperature | (-55℃～+95℃) | ||||||
| Environmental | |||||||
| Vibration | 16.4G(10-2000Hz) | ||||||
| Shock(Operating) | 1500G(0.5ms,Half sine wave) | ||||||
| Humidity | 5%～95%（No Condensing） | ||||||
| Reliability | |||||||
| MTBF | 2000000hrs | ||||||
| Data Retention(Max): | 10 Years@25℃ | ||||||
| Special Functions | |||||||
| Power Loss Protection | √ | ||||||
| Conformal Coating | √ | ||||||
| Secure Erase | Optional | ||||||
| TRIM | √ | ||||||
| S.M.A.R.T | √ | ||||||
